20CBM HOWO heavy duty dump truck 371 hp engine with WABCO System / Strengthen Bumper
Specifications:
| Vehicle name | HOWO 6×4 Tipper | Vehicle models | ZZ3257N2947A |
| Engine Model | WD615.69/WD615.47 | Engine power(ps) | 371hp |
| Emission standard | Euro Ⅱ | Steering | ZF8118 hydraulic steering with power assistance |
| Cab | HW76 | Transmission | HW15710(19710), 10 forward, 2 reverse |
| Overall dimensions(mm) | 6500×2496×2958 | Van internal dimensions (mm) | 4800 x2300 x1200 |
| Total mass (kg) | 25000 | Axle-load (kg) | 12700 |
| Kerb weight (kg) | 8550 | Approach angle / departure angle (°) | 19/66 |
| Wheelbase(mm) | 2925+1350 | Front overhang / Rear overhang (mm) | 1500/725 |
| Maximum speed(km/h) | 75 | Axle-load | 7000/18000 (Dual-axles) |
| Tire number | 10 | Tire type | 11.00-20/11.00R20
12.00-20/12.00R20 |
| Front tread(mm) | 2022 | Rear tread(mm) | 1830/1830 |
| Cab | HOWO70 cab, (single sleeper, with air-condition), all-steel forward control,70ºhydraulically tiltable to the front, 2- arm windscreen wiper system with 3 speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers |
| Instrument Panel | Active check central control with indicators, with this integral instrument the daily manual checks on the vehicle and combined indicators of compressed air pressure, coolant temperature, engine oil pressure and battery charging |
Description:
That engaged in developing and manufacturing special truck and components, the modern professional enterprise is a public announcement management company of the Ministry of Industry and Information and is a major transportation equipment manufacturing enterprise in Jinan City.
Our company mainly manufacturing the dump truck, concrete pump truck, fuel tank truck, water sprayer truck ,compression garbage truck, sewage suction truck, sprinkling truck, powder material truck, municipal engineering vehicles, semi-trailers, new energy automobile, products are sold all over the country and exported Southeast Asia, Africa, North America, the Middle East, Russia and other markets.
Applications:
It is suitable for in normal roads and tough roads, to transport and unload transport, stone, ore, and others loose materials.
Competitive Advantage
1, The price is competitive; we are the direct channel to supply the dump truck
2, Powerful engine and strong frame, which can suit to all kinds of road conditions, especially for the tough roads
3. Sinotruk dump truck adopt many key technologies both from home and abroad, and it can achieve the best design and be in good conditions.
4. Low oil consumption. Sinotruk adopt the engine that combine the MAN and technolgoy, it has the perfect oil performance.
5. Sufficient stocked spare parts are available for you when you need to repair your dump truck
6. with the same conditions, our dump truck can be used for a longer time as we used many world famous brand spare parts and assembly.
